wolfer电机广泛应用于起重设备,造船设备,功率从2.2KW-2000KW
Wolfer经过65年的制作研发,Wolfer已经研发和生产的电动马达广泛地用于起重设备,在和船舶上以及在一般机械工程。我们运用我们的广泛知识生产高效电动机相适应的激励机制的解决方法。在我们的工作地点在Osnabruck员工努力工作以确保达到质量标准。客户遍布世界各地的人相信的表现能力,增强肌肤紧实度、动力学和高度的高效率的创新产品。 电机生产过程中的提升人类的确是世界领先的生产商之一有关质量以及技术。
Hoisting equipment Three phase asynchronous motors made by Wolfer stand out on account of their robust design and their very high performance capacity. They are individually manufactured in accordance with our customers' requirements. The use of special rotors with appropriately adapted geometry makes it possible to achieve excellent control qualities. A high pull out torque guarantees safe operation in the field weakening. On account of their low moment of inertia, these highly dynamic drive motors have the advantage of shorter acceleration time combined with reduced frequency converter current. Consequently smaller frequency converters and reduced cable cross sections can frequently be used. Nominal voltages up to a maximum of 690 volts as well as frequencies and rated speeds are freely selectable for our motors, providing physical and mechanical limit values are observed. Special insulations and special winding wires are used which are almost completely resistant to partial discharges which ensue in frequency converter operation. Many different kinds of control and protection equipment are also available. Furthermore, it is also possible to integrate holding brakes, separately driven fans and other components. All the motors have excellent regulation properties which also mean low life-cycle costs.
由三相异步电动机Wolfer脱颖而出的缘故,他们精湛的设计和他们的超高性能的能力。他们是单独制造符合我们客户的需求。采用特殊转子几何与适当的改编使得它能够实现良好的控制品质。高拉出扭矩安全运行提供保障在田间弱化。由于低惯性矩的,这些高度动态驱动马达拥有优势较短的加速时间结合减少变频器电流。因此较小的频率转换器和降低电缆截面经常不被使用。 名义上的电压,最多不超过6,900伏特以及频率和额定速度对我们自由的马达,可提供物理力学限制价值观是观察到的现象。特殊绝缘和特殊的绕组线使用几乎被完全抵抗局部放电,产生对变频器运行。许多不同种类的控制和保护设备也可。此外,它也有可能来整合控股制动器,分别驱动风扇和其他组成部分。所有的电动机有良好的调节性能也意味着低寿命周期成本。
Three-phase asynchronous motors – squirrel cage and slipring motors range of power: 2.2 to 2000 kW frame sizes 100 to 560 in conformity with IEC types of protection IP 23 to IP 56 nominal voltage up to 690 V in 4-, 6-, 8- or 10-pole design designs: all in conformity with IEC standard types of cooling: self-ventilated, separately ventilated, without ventilator, heat exchanger.
造船 我们的紧凑而建造使用特殊电机在极端压力条件在船舶工业,特别是对于弓和严厉的推进器在集装箱船和集装箱能力超过5000个标准箱。他们比赛的规则,履行所有著名船级社的要求,并说服绝缘等级为F由他们的优化能量平衡。也可提供这些电机热交换器。此外控股的刹车,分别驱动的球迷,以及加热器和其他元件可以另外综合。 松鼠笼电机等弓或者严厉的推进器 启动程序的最佳利用。 star-delta-start, 开始transformator 变频器 推荐了一个隔离轴承电机变频运行。 电动机启动或弓式推进器 利用电阻调速可以关掉 起重机电机血管 开始特点进行 优良的控制特点,也是在高距离的速度 低惯性矩的 Winchmotors 变频器调速的频率 保护IC410 IP56,类型的冷却 配有刹车和编码器为境外申请
